Google Kubernetes Engine —  HorizontalPodAutoscaler with external metrics from PubSub

There are certain use cases where scaling horizontally based on cpu usage does not really work well. Let’s say you have a consumer worker pool running in Kubernetes. The consumers are pulling messages from a PubSub topic. When the queue is filling up we want more workers to process the messages quickly. On the other hand, when the queue is empty, we don’t want to pay for a big worker pool that sits idle. With PubSub Stackdriver metrics adapter running on GKE we can easily autoscale our worker pool for minimum latency and maximum cost-effectivity.

Autoscaling Deployments with External Metrics

This tutorial demonstrates how to automatically scale your GKE workloads based on metrics available in Stackdriver.

If you want to autoscale based on metric exported by your Kubernetes workload or a metric attached to Kubernetes object such as Pod or Node visit Autoscaling Deployments with Custom Metrics instead.

This example shows autoscaling based on the number of undelivered messages in a Cloud Pub/Sub subscription, but the instructions can be applied to any metric available in Stackdriver.

Stackdriver Cloud Pub/Sub Monitoring

Provision GCP resources

We’ll be using terraform here to provision all necessary GCP resources. The cluster and nodepool’s definition is in file main.tf. Make sure to follow all the steps in README to create a service account for terraform with all necessary permissions to create all the resources.

Then run:

terraform init
terraform plan -out planfile
terraform apply planfile

The PubSub topic will be named “echo”, the subscription to it “echo-read”. If you’ve run terraform apply successfully, this is provisioned already.

resource "google_pubsub_topic" "echo" {
  name = "echo"
}


resource "google_pubsub_subscription" "echo" {
  name  = "echo-read"
  topic = "${google_pubsub_topic.echo.name}"

  ack_deadline_seconds = 20
}

Deploy Stackdriver metrics adapter

Make sure you have kubectl installed and you can access the cluster.

Deploy the stackdriver adapter:

kubectl create -f https://raw.githubusercontent.com/GoogleCloudPlatform/k8s-stackdriver/master/custom-metrics-stackdriver-adapter/deploy/production/adapter.yaml

Deploy the HPA and deployment

Here’s how the HPA’s definition look like:

apiVersion: autoscaling/v2beta1
kind: HorizontalPodAutoscaler
metadata:
  name: pubsub
spec:
  minReplicas: 1
  maxReplicas: 5
  metrics:
  - external:
      metricName: pubsub.googleapis.com|subscription|num_undelivered_messages
      metricSelector:
        matchLabels:
          resource.labels.subscription_id: echo-read
      targetAverageValue: "2"
    type: External
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: pubsub

We’ll autoscale between 1–5 replicas, based on external metric pubsub.googleapis.com|subscription|num_undelivered_messages from our echo-read subscription.

The target value is 2 undelivered messages. What does it actually mean though?

Example: let’s say my deployment is currently running 3 replicas and my queue grows from 6 to 8 undelivered messages.
I have 8/3=2.6 undelivered messages per replica.
That hits the threshold and triggers a scale-out to 4 replicas, which will have 8/4=2 undelivered messages per replica and that fits the desired targetAverageValue.
If I had 50 undelivered messages, I will have 5 replicas as it’s my maximum.
If I had 0 undelivered messages, I will have 1 replica as it’s my minimum.

The scaleTargetRef is a reference of the resource that I’m autoscaling. It’s a deployment that is defined in file pubsub-deployment.yaml.

Deploy the HPA with the deployment that is going to be autoscaled:

kubectl apply -f  pubsub-hpa.yaml
kubectl apply -f  pubsub-deployment.yaml

Test it!

Publish some messages to the topic

for i in {1..200}; do
   gcloud pubsub topics publish echo --message=”Autoscaling #${i}”
done

And watch the cluster’s resources doing its magic

watch 'kubectl get pods; echo ; kubectl get hpa'

Summary

With this simple setup, you have a pretty decent setup for horizontal autoscaling. The ugly thing is running the stackdriver adapter yourself, at least the HPA controller is part of GKE and is fully managed for you.
The other cool thing about HPA is that you can use multiple metrics (even a combination of custom/external/cpu) in the same HPA resource and your deployment is going to be scaled based on either of them hitting a threshold.

Links

https://github.com/marekaf/gke-hpa-stackdriver-pubsub

https://cloud.google.com/kubernetes-engine/docs/tutorials/authenticating-to-cloud-platform

https://cloud.google.com/kubernetes-engine/docs/tutorials/external-metrics-autoscaling

FAQs

Q1: For what kind of workload is scaling based on CPU usage not effective?

Scaling based on CPU usage is not very effective for use cases like a consumer worker pool pulling messages from a Pub/Sub topic. In this scenario, it is more desirable to scale the number of workers based on the number of messages waiting in the queue rather than the CPU load of the workers.

Q2: What is the proposed solution for autoscaling a Pub/Sub consumer pool on GKE?

The solution is to use the Pub/Sub Stackdriver metrics adapter on GKE. This allows you to configure a HorizontalPodAutoscaler (HPA) to automatically scale the number of worker pods based on the number of undelivered messages in a specific Pub/Sub subscription, ensuring minimum latency and maximum cost-effectiveness.

Q3: What component is required to allow Kubernetes to use metrics from Stackdriver for autoscaling?

You must deploy the Stackdriver metrics adapter to the cluster. This adapter makes metrics from Stackdriver, such as the Pub/Sub queue depth, available to the Kubernetes HPA controller so it can make scaling decisions.

Q4: How is the HorizontalPodAutoscaler (HPA) configured to monitor the Pub/Sub queue?

The HPA is configured with a metric of type External. It specifies the metricName as pubsub.googleapis.com|subscription|num_undelivered_messages and uses a metricSelector to target the specific Pub/Sub subscription ID that needs to be monitored.

Q5: How does the targetAverageValue setting in the HPA work?

The HPA attempts to maintain an average value of the specified metric per replica that is equal to the targetAverageValue. For example, with a target value of “2,” if there are currently 8 undelivered messages and 3 running replicas, the average value is 2.6 (8 divided by 3). Since this is higher than the target, the HPA will scale out to 4 replicas, which brings the new average down to 2 (8 divided by 4).

Q6: Can a HorizontalPodAutoscaler use more than one metric to make scaling decisions?

Yes, you can use multiple metrics in the same HPA resource, including a combination of custom, external, and CPU-based metrics. The deployment will be scaled if any one of the defined metrics hits its threshold.

Q7: What is mentioned as the main downside of this particular autoscaling setup?

The main “ugly thing” about the setup is that you have to run and manage the Stackdriver adapter yourself. However, the HPA controller itself is a part of GKE and is fully managed for you.
